Hot And Cold Water Sterilizer

About Hot And Cold Water Sterilizer

HOT AND COLD-WATER STERILIZER

       Model No: LM-WS-30L

       Usage/Application - Hospital

       Automation Grade - Fully Automatic

       Description: Hot and Cold Water  Sterilizer

       Brand: LuxMed

       Country: Made in India

       Capacity: 30  to 50  Liters

       Material: Stainless Steel 304/316

       Power Supply:  12KW

       Insulation Wall: Double Wall with Insulation

       Available Sizes: 30 to 50 Liters

The unit consists of two separate stainless-steel tanks; one is for sterile hot water and the other is for sterile, cold water; both are mounted on a sturdy S.S. cover stand Each tank has an individual heater bank, low water cut-off pressure controller & conductor. The unit consists of individual control such as a safety valve, pressure gauge, steam trap, self-sterilizing water filter, water level gauge indicator, air & water filter and draw-off water valve with socket, safety valve, double-acting valve, etc. The sterile water chamber additionally fitted with a cooling coil for circulation of cold water.

Construction and Salient Features

       Type of Sterilizer: Hot and Cold Sterilizer

       Double/ Triple walled unit vertically mounted on a sturdy, heavy Stainless Steel.

       Both inner chamber and outer wall made of Stainless Steel 304/316.

       Power Supply: 12kW

       Capacity: 30-50 Liters

       Application: Hospital

Stainless Steel Hot Cold Sterilizer with separate Hot cold sterile water

Aseptic devices include self- sterilization elimination of water recontamination.

Cold water sterilizer is fitted with a cooling coil for circulation of water from the main.

Unit rests on elegantly finished tubular stand

The unit consist of individual controls such as safety valves, pressure gauge, steam trap, self-sterilizing water filter , water level indicator and air filter
