Send InquiryLaboSys Multistage Ultrasonic Cleaning System
Price 750000.0 INR/ Piece
MOQ : 1 Piece
LaboSys Multistage Ultrasonic Cleaning System Specification
- Dimension (L*W*H)
- 1500 mm x 600 mm x 900 mm (customizable)
- Material
- Stainless steel
- Floor
- Anti-skid ribbed SS base
- Thickness
- 2-4 mm (Tank wall thickness)
- Nozzle
- SS Spray Nozzles/Jet for rinsing stages (optional)
- Lighting
- Integrated Indicator Lights (Optional)
- Application
- Industrial precision cleaning, Laboratory equipment, Electronics, Medical instruments
- Power Consumption
- Multipoint, 1.5 kW to 8 kW (depending on stages/capacity)
- Type
- Other
- Filter Type
- Cartridge/In-line
- Door
- Yes
- Frame Material
- Stainless Steel
- Feature
- PLC control, Multiple process stages (Ultrasonic, rinsing, drying), Digital Timer & Heater, User-friendly interface, Low maintenance
- Weight
- Approx. 120-200 kg (depends on system configuration)
- Voltage
- 110-215 Volt (v)
- Condition
- New
- Filters
- Micron Cartridge/In-line Filters (as per process)
- Drying System
- Hot Air Blower/Heated chamber (optional)
- Number of Stages
- 2 to 5 (customizable as per requirement)
- Heating System
- Integrated SS immersion heaters with thermostat control
- Ultrasonic Frequency
- 28/33/40 kHz (selectable)
- Drainage System
- Individual tank drain outlets with valve
- Control Panel
- Digital/PLC based with process sequence automation
- Basket Material
- Electropolished Stainless Steel
LaboSys Multistage Ultrasonic Cleaning System Trade Information
- Minimum Order Quantity
- 1 Piece
- Delivery Time
- 20 Days
About LaboSys Multistage Ultrasonic Cleaning System
LaboSys Multi-Stage Ultrasonic System - Ultrasonic Cleaning followed by Rinsing & Drying tank.Multi Tank or Multi Chamber Ultrasonic Cleaning machines are ideal for production lines where usually a bulk quantity has to be cleaned daily. Multi Chamber Ultrasonic Cleaning machine becomes a part of the manufacturing line which enables voluminous cleaning of different types of parts. A usual Multi Tank Ultrasonic Cleaning Machine comprises of the following stages; Ultrasonic Cleaning followed by Rinsing & Drying tank. However, the stages can be customized and added up to 10 tanks or more depending upon the process requirement.
Types of Muti -Tank Ultrasonic Cleaning Machines:
Manual Enables manual transfer of baskets from one tank to another
Semi- Automatic Enables pneumatic dunking and push slide basket arrangement
Fully Automatic Enables minimum human intervention with auto basket transfer from one tank to another Models of Ultrasonic Multi Tank Cleaning Machines:
MSUS 2 Ultrasonic Cleaning + Heated Rinsing
MSUS 3- Ultrasonic Cleaning + Heated Rinsing + Drying
MSUS 4 Ultrasonic Cleaning + Ultrasonic Rinsing + Heated Rinsing + Drying Machine Features
Oil-Skimmer options
Low Level float sensors
Options of Filtration Unit
Low noise working modules
Duly Passivated tanks for longevity
Digital Timer & Temperature controllers
Fully insulated stainless steel working tanks
https://www.luxmed.in/
Advanced Customization for Versatile Cleaning
LaboSys offers complete flexibility in configuration, ranging from 2 to 5 stages, with dimensions and features tailored to user requirements. This adaptability ensures the system meets various industrial and laboratory standards, optimizing cleaning processes for intricate and sensitive components.
Precision Control and Efficient Operation
Equipped with digital or PLC-based control panels, the system enables automated process sequences, precise timer and heating control, and a user-friendly interface. Selectable ultrasonic frequencies and multipoint power options allow fine-tuning for different contamination levels and substrates, ensuring consistent results.
Commitment to Safety and Hygiene
Constructed from electropolished and ribbed stainless steel, the cleaning tanks and baskets maximize cleanliness and structural integrity. Safety features include individual drain outlets with valves, anti-skid flooring, and integrated heater thermostats, supporting reliable operation in rigorous settings.
FAQ's of LaboSys Multistage Ultrasonic Cleaning System:
Q: How does the LaboSys Multistage Ultrasonic Cleaning System operate across multiple stages?
A: The system operates by passing items through up to five customizable cleaning stages, which may include ultrasonic cleaning, rinsing, and optional hot air drying. Each stage can be adjusted for specific process requirements using digital or PLC-based controls, ensuring targeted and thorough cleaning suited to your application.Q: What applications is this ultrasonic cleaning system suitable for?
A: It is ideal for industrial precision cleaning, laboratory equipment maintenance, electronics manufacturing, and medical instrument sterilization. Its customizable design and robust stainless steel construction cater to environments demanding high cleanliness standards and reliable performance.Q: When should I choose a specific ultrasonic frequency (28/33/40 kHz)?
A: Selection depends on the type of contaminants and delicacy of the items being cleaned. Lower frequencies (28 kHz) are effective for heavy or stubborn residues, while higher frequencies (40 kHz) are better for gentle cleaning of sensitive or intricately detailed components.Q: Where can the system be installed, and are the dimensions adjustable?
A: The LaboSys system can be installed in laboratories, medical facilities, electronics production units, and industrial workshops. Dimensions are customizable to accommodate space constraints and process volume, ensuring seamless integration into your workflow.Q: How does the integrated heating and drainage system enhance cleaning efficiency?
A: Integrated SS immersion heaters with thermostat control help maintain optimal cleaning temperatures, improving contaminant removal. Individual tank drain outlets with valves facilitate rapid water change and easy maintenance, supporting continuous, efficient operation.Q: What are the user and maintenance benefits of the system's design features?
A: User-friendly digital controls and PLC automation make operation straightforward, while low-maintenance stainless steel components and micron filtration systems minimize downtime. Anti-skid ribbed bases and optional indicator lighting further promote safety and ease of use.
