LuxMed Multi Device Charging Station

OVERVIEW

Grid Power 230Vac / 110Vac

Solar / or DC 24Vdc

UPC Code

LSCS0048AC

LSCS0048DC

Product Type

Multi-Device Charger

Multi-Device Charger

Charging Form Factor

Stationary Cabinet

Stationary Cabinet

Charger Functions

Charge; Secure; Sync

Charge; Secure; Sync

Device Compatibility

Tablet; Phone

Tablet; Phone

Device Slots

48

48

INPUT

Nominal Input Voltage(s) Supported

120V AC; 230V AC

24Vdc

Voltage Compatibility (VAC)

110-240

18 to 30Vac

Input Frequency

50 / 60 Hz (auto-select)

DC Solar / Battery

Input Plug Type

NEMA 5-15P

NEMA 5-15P

Input Cord Length (ft.)

10

10

Input Cord Length (m)

3.05

3.05

POWER

Grid Power 230Vac / 110Vac

Solar / or DC 24Vdc

Power Consumption (Watts)

224

224

CHARGING

Number of Charging Ports

48

48

Total Charging Amps

120A

120A

Total Charging Watts

600

600

Charging Method

USB

USB

Charging Port Type

USB A (FEMALE)

USB A (FEMALE)

Charging Ports Details

Pass through

Pass through

Charging Ports / Amps

(48) 2.4A

(48) 2.4A

Overcharge Protection

Yes

Yes

Charging Amps per Port

2.4A

2.4A

PHYSICAL

Color

Black

Black

Material of Construction

Steel

Steel

Charging Station Form Factor

Stationary Cabinet

Stationary Cabinet

Shipping Dimensions (hwd / in.)

41.02 x 28.35 x 26.38

41.02 x 28.35 x 26.38

Shipping Dimensions (hwd / cm)

104.19 x 72.01 x 67.01

104.19 x 72.01 x 67.01

Shipping Weight (lbs.)

183

183

Shipping Weight (kg)

83.01

83.01

Slot Dimensions - Bottom (hwd / in.)

8.0 x 0,8 x 13,9

8.0 x 0,8 x 13,9

204 x 20,1 x 353.8

204 x 20,1 x 353.8

Slot Dimensions - Middle (hwd / in.)

8.0 x 0,8 x 13,9

8.0 x 0,8 x 13,9

Slot Dimensions - Middle (hwd / mm)

204 x 20,1 x 353.8

204 x 20,1 x 353.8

Slot Dimensions - Top (hwd / in.)

8.1 x 0,8 x 13,9

8.1 x 0,8 x 13,9

Slot Dimensions - Top (hwd / mm)

206 x 20,1 x 353.8

206 x 20,1 x 353.8

Unit Dimensions (hwd / in.)

35.630 x 23.620 x 21.570

35.630 x 23.620 x 21.570

Unit Dimensions (hwd / cm)

90.42 x 59.9 x 54.86

90.42 x 59.9 x 54.86

Unit Weight (lbs.)

150

150

Unit Weight (kg)

68.04

68.04

Number of Shelves

3

3

FEATURES & SPECIFICATIONS

Antimicrobial

No

No

Built-In Circuit Breaker

Yes

Yes

Cord Management

Yes

Yes

Overcurrent Protection

Yes

Yes

EMI/RFI Line Noise Protection

Yes

Yes

Flow-Through Ventilation

Yes

Yes

IP68 Rated

No

No

IP20 Rated

No

No

UV Sterilization

No

No

Locking

Yes

Yes

Lock Type

Key

Key

STANDARDS & COMPLIANCE

Product Certifications

NOM (Mexico); UL 60950-1

NOM (Mexico); UL 60950-1

Product Compliance

RoHS; CE (Europe); EIA/ECA-310-E; REACH;

FCC Part 15 Class B (USA)

RoHS; CE (Europe); EIA/ECA-310-E; REACH;

FCC Part 15 Class B (USA)

WARRANTY & SUPPORT

2-year limited warranty

2-year limited warranty

CATEGORY PAGE FILTERS (Y/N ONLY)

External Receptacle

No

No
