LuxMed Single Door Rectangular Steam Sterilizer

About LuxMed Single Door Rectangular Steam Sterilizer

H2 (Size 4): LuxMed Horizontal High Pressure High Vacuum Steam Sterilizer Rectangular Type with Vertical Double Door

LuxMed horizontal, high-pressure, high-vacuum steam sterilizer comes with a rectangular chamber, vertical double door, integrated steam generator, and fully automatic operation.

H2 (Size 4): Chamber and Jacket

Size: Ref. Inline Table A and B
Volume: Ref. Inline Table A and B
Working Pressure: 2.2 kg
Working Temperature: 121C to 135C
Material: SS304

The chamber is fabricated with full argon/LASER welding and rounded corners for easy cleaning, with a 2% slope for complete drainage. It includes safety valves and compounding gauges on both sides. Pure steam is used for sterilization. SS304 removable circular-section railings are provided for easy cleaning.

H2 (Size 4): Parts and Accessories

Water-Based Vacuum Pump: Kirloskar 1HP Three-Phase Mono-block Pump (Model KV-20) for pre- and post-vacuum.
Water Filling Pump: Kirloskar Chotu 0.5HP pump for auto water filling.
Chamber Baffles: SS304.

H2 (Size 4): Jacket

Material: SS304
Working Pressure: 2.5 kg
Working Temperature: 138C
Ensures uniform heating in the sterilization chamber.

H2 (Size 4): Insulation of Shell

The chamber and doors are insulated with 50mm resin-bonded glass wool and cladded with SS304 sheets, ensuring external surface temperature does not exceed 55C.

H2 (Size 4): Door Handle and Lever

Manual door handle and lever are provided with silicone covers for safety and insulation.

H2 (Size 4): Steam Generator

A steam generator (Ref. Inline Table A and B) is mounted below the chamber to supply dry saturated steam to the jacket and chamber via a steam dryer. DM water must be supplied by the client for pure steam generation.

H2 (Size 4): Door Manual Operation

Available with single or double manual doors. Doors are made of SS304 and sealed with a movable silicone gasket. Door status indicators are provided on both sides. Safety features include interlocking (for double-door models) and obstruction detection.

H2 (Size 4): Flush Mounting

SS304 sheets are provided on the unloading side and fixed to the wall to prevent cross-flow of sterile air into the non-sterile area, ensuring proper separation.

H2 (Size 4): Valves and Piping

All chamber-contact valves and pipelines are SS304; non-contact components are also SS304. Solid-bar connectors prevent cracking. All pipelines are argon-welded with smooth finishing.
Process valves are sanitary-grade. All utility connections are grouped at a single corner for easy access.
Drain lines include a removable screen plug to prevent clogging.
Pneumatic lines are made of copper tubing with brass/SS connectors.
